25B21FT

Name: 25B21FT
Brand: Bigfoot RV

The 25B21 combines Bigfoot's legendary insulation with versatile layouts designed for maximum comfort and privacy.

02Specs & Features

Detailed specifications for 25B21FT.

Overall Length21'-6" (6.55 m) (Does not include optional Front Cargo Box)

Overall Width8'-4" (2.54 m)

Overall Height8'-10" (2.69 m) (To top of the refrigerator vent)

Interior Height6'-4" (1.93 m)

Base Dry Weight4,553 lb (2,066 kg)

Hitch Weight490 lb (184 kg)

Axle Rating2×3,500 lb (2×1,588 kg)

GVWR7,500 lb (3,400 kg)

TiresST225/75R15

Fresh Water34 gal (128 L)

Grey Water27 gal (102 L)

Black Water22 gal (84 L)

LPG Capacity2×30 lb (2×18 L)

Water Heater6 gal (23 L)

Furnace30,000 BTU

Fridge6 cu ft (169 L)

Standard features included on every 25B21FT — built in at the factory.

Lightweight Two Piece Fiberglass Exterior Shell
1 1/2” High Density EPS Insulation (R8)
Radius Corner Solar Reflective Safety Glass Thermal Pane Windows with Screens
Folding Assist Handle
Aluminum Covered Rear Bumper
E-Z Lube Wide Track 3,500 Lbs Axle with Self Adjusting Electric Brakes
Spare Tire and Carrier
Aluminum Wheels
Continental Tire Kit
Break Away Switch
Stabilizer Jacks (front & rear)
Power Tongue Jack
LED Exterior Clearance and Directional Lighting
Molded Fiberglass Rock Guard with Gas Struts
Ladder
Solar System - 400W Solar Panels with MPPT Bluetooth Charge Controller & Display
Electric 14' Awning
Molded Fibreglass Propane Bottle Cover
Dual 30 lb Propane Tanks with Auto Changeover & OPD Valves
Folding 2-Step
Porch, Hitch and Roadside Lights

Electrical Battery Disconnect
Electrical 120 VAC / 30 Amp Service / 45 Amp DC Power Converter with Battery Charger
Pre-wired for Roof Air Conditioner
Power Fan in Bathroom
Maxxair Fan (choice of location)
Battery Ready
Detachable 30 Amp Power Cord

Options available for the 25B21FT — tailor your build through your dealer.

Air Conditioner - MACH 10 NDQ - 13,500 BTU
Air Conditioner - Truma Aventa Eco
Winegard AIR 360 & LP 5G Antenna
Exterior Stereo Speakers
Maxxair Exhaust Fan (Bathroom)
Maxxair 2 Way Fan (Bedroom and/or Galley)
Fiberglass Front Cargo Box (Adds 2' to length of Trailer)
Generator Ready Package with Auto Transfer Switch
Generator - Cummins Onan 2.5kW Propane
LCD 12 Volt TV
Leather Decor Upgrade (Simulated)
Privacy Curtain
RV BBQ Hook Up
Receiver for 2" Bike Rack
Rear Roof Rack
Rollaway Shower Door
Wireless Rear View Camera System
Truma Combi Comfort Plus (replaces hot water heater & furnace)
Truma Aquago (On Demand Water Heater)
EcoFlow Power System - includes 5kW Lithium Battery and 3.6kW Inverter with option of adding 2kW and 5kW Batteries, includes 400W solar panels
Four Inch Lift
